Newest Endolaser 1470nm 980nm Diode Laser Face Endolaser With Fiber Optic Laser Lipolysis Lipolysis Weight Loss

980nm + 1470nm Diode Laser System
Treatment Principle

The 980nm + 1470nm diode laser system utilizes advanced semiconductor laser technology with dual wavelengths to achieve precise and efficient tissue treatment.

Laser energy is delivered through an optical fiber, allowing highly targeted therapy. The wavelengths are selectively absorbed by hemoglobin and water within cells, enabling precise thermal action in small treatment areas. This process allows tissues to be rapidly vaporized, coagulated, and decomposed, while minimizing damage to surrounding tissues.

Thanks to its excellent cutting efficiency, coagulation ability, and hemostatic effect, the system is widely used in various minimally invasive medical procedures, including:

• Tumor resection
• Surgical procedures
• Prostate treatment (prostatectomy)
• Varicose vein treatment
• Other minimally invasive operations



Lipolysis Treatment Principle

The semiconductor laser therapy device combines 980nm and 1470nm wavelengths with a fiber-coupled laser system and a disposable lipolysis fiber to perform precise fat reduction treatments.

The optical fiber is inserted through an ultra-fine needle to accurately target localized fat deposits. Laser energy is delivered directly to the adipose tissue, where it:

• Rapidly dissolves and liquefies fat cells
• Generates uniform heating within deep and superficial fat layers
• Alters the structure of connective tissue and fat cells through controlled thermal energy

During the treatment process, the laser produces both photothermal and photodynamic effects:

• Photothermal effect: heats and liquefies fat cells
• Photodynamic effect: separates fat cells from surrounding tissues

The liquefied fat is then naturally removed through the ultra-fine cannula, effectively reducing the number of fat cells and minimizing the risk of postoperative fat rebound.

Technology Parameters:

Output	Fiber-optic coupling
Laser wavelength	980nm+1470nm
Output Power	980nm20W+1470nm3W
Pulse width	1ms-60ms
Frequency	1-9HZ
Mode	Pulse mode & CW mdoe
Aiming optical	650nm
Input	AC:100-240V,50/60Hz
Operation interface	10.4 inch
language	English or OEM
Length of Fiber	3m
Fiber core diameter	600μm
Cooling	Air cooling
Net/Gross weight	5KG/10KG
Machine Dimensions	385mm*345mm*335mm
Flight case Dimensions	540mm*400mm*360mm
